| Brand Name: | Turboo |
| Model Number: | ES3012 |
| MOQ: | 1 PC |
| Price: | Negotiable |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T, L/C |
| Technical Data | Units | 1 |
| Passage width | mm | <=900 |
| Throughput rate | p/m | 35 |
| Power supply | V(ac) | 100-240 |
| Operational voltage | V(dc) | 24 |
| Max power consumption | w | 35 |
| Frequency | hz | 50-60 |
| prectection level | ip | 44 |
| Working temperature | degree | -25 to +70 |
| Dimension excluding bars | mm | 1200X185X980 |
| Net weight including bars | Kg | 85 |
Features and Benefits
1. Stainless steel box, box-type bevel shape, novel and beautiful, durable.
2. Sunscreen, Anti-temperature, Anti-cold.
3. Access Prompt function:Red and green light prompt the passing information.
4. The programmable gates control state, with a variety of operating modes you can choose,
you can set a one-way or two-way control
5. Compatible IC, ID, magnetic card, bar code card, and other control equipment.
6. Small button int the main control panel ,can be set state of equipment.
Communication
• Dry contact relay with 12 volt or 24 volt pulse
• Rs485, or Tcp-lp communication with computer
Product details
