| Brand Name: | Turboo |
| Model Number: | H203 |
| MOQ: | 1 PC |
| Price: | Negotiable |
| Delivery Time: | 10 Working Days |
| Payment Terms: | L/C, T/T |
Features and Benefits
1.Use IC cards, ID cards, Bar code or magnetic cards as automatic identification system and achieve access, attendance fees or function.
2. A direction indicator, showed that pedestrian access to the current status of, and guide pedestrians correct and smooth passage.
3.Display has been in use for statistics and numbers
4. A combination of infrared sensors and police anti-illegal entry into pedestrian access, the protection of pedestrians access smooth and the prevention of the channel following.
5.Communication
•Dry contact relay with 12 volt or 24 volt pulse
•Rs485, or Tcp-lp communication with computer
Operating modes
1. Single passage in the set direction
2. Bi-directional single passage
3. Free passage in the set direction
4. Always free or locked
Materials
1. Housing: In stainless steel AISI 304 or AISI316.
2. Barrier arm- stainless steel bar.
Specifications
| Technical Data | H203 |
| Dimension | 1410x340x1005mm |
| Unlock time | 0.2s |
| Passage width | ≤550mm |
| Throughput rate | 35p/m |
| Power supply | 100~240v |
| Operational voltage | 24v |
| Max power consumption | 30w |
| Frequency | 50~60hz |
| Prectection level | 44ip |
| Working temperature | -25~70 °C |
| Electro-magnetic drive | DC |
| Net weight | 35kg |
| Input | 12v dry contact |
