900mm Width RS485 Optical Swing turnstile For Hotels Gyms wit Brushless Control System

name

900mm Width RS485 Optical Swing turnstile For Hotels Gyms wit Brushless Control System

Brand Name:	Turboo
Model Number:	H309
MOQ:	1 PC
Price:	Negotiation
Delivery Time:	5~10 Working Days
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE

Material:

1.2mm 304SS+1.2mm Top Cover Cold Rolling

Passage Width::

600-900mm

Install Place::

Indoor/Outdoor

Driving Voltage::

24 V

Environment::

-25~+70

Passing Speed:

35 Person/min

Interface:

RS485,TCP/IP,Dry Contact,Switch Signal

Warranty:

12 Months

Color:

Black & Grey,Metallic Silver

Application:

Commercial Building,hotel

Packaging Details:

Carton or Wooden Case Package

Supply Ability:

1000 units per month

Highlight:

RS485 Optical Swing Turnstile

,

Hotels Gyms Optical Swing Turnstile

,

900mm Width Pedestrian Barrier Gate

Product Description

900mm Width RS485 Optical Swing turnstile For Hotels Gyms wit Brushless Control System

Speed Swing Barrier Turnstile Description

Turboo new design speed barrier turnstile gate model H309, pedestrian automatic access control system waist height 304 stainless steel swing gate, with RFID card, fingerprint identification and face verification mode.Combined with infrared detector, temperature controller, revolving door series product design novel, can be widely used in subway, school, office, scenic area, gym, factory, residential, supermarket and other places.Control System : All inputs are opto-coupler protected .Controlled by dry contact or grounding input. Compatible with all access control systems that provide dry contact or grounding outputs. Optional RS232/RS485/TCP IP control module is available.System Features& Operation : Normally Closed Position: The wings are closed crossing the lane at standby. Wings open rapidly to allow passage when input is received by either direction. Internal dip switch selectable free passage by photocell detection, restricted access, controlled access on both or single direction modes are built in features.

Model No.H309
Dimension1500*120*980mm
Material1.2mm SUS304 Hairline 400#
Flap material10mm Acrylic
Passage Width600-900mm
Passage directionSingle directional/Bi-directional
Passing rate30-35 persons/minute
Operating time0.2 seconds
Power inputAC100-240V,50/60HZ
Working voltage24V
Working humidity30%~95%
Working temperature-40℃~+70℃
Working environmentIndoor/outdoor
Communication interfaceRS485, Dry contact
MechanismBrushless motor
Infrared sensor6 pairs
MCBF5 million Cycles
ApplicationOffice, Hotels, Commercial buldings, etc

900mm Width RS485 Optical Swing turnstile For Hotels Gyms wit Brushless Control System 0
